Design with 23mm internal width with tubeless and hookless rim profile ideal for wider tires at lower tire pressure
Minimum 25mm tire width
More than 300 g lighter than previous model
ZR1 DB hub is engineered in Germany with better seal design for improved durability and quicker response with 66 points of engagement
Built with Sapim CX Sprint J-bend spokes
An all-out aero 80mm rim profile
ABLC Sawtooth™ dimple design helps manage air flow around the rim, and contributes to create a faster, more stable wheel
Center locking rotor interface. Lockring is included
XDR™ or SRAM/Shimano driver bodies
Ships with 12mm front and rear end caps
Lifetime warranty
Zipp graphics and cosmetic identity that scream speed
Campagnolo driver body sold separately
Superior modulation and stopping power of disc brakes

SPECIFICATIONS
Size (wheels) 700c
Rim construction: Carbon – Hookless
Tire compatibility: Tubeless tires only
Rim depth: 80mm
Brake compatibility: Disc (Center Lock)
Rim - inside width: 23mm
Rim profile: Symmetrical
Rim finish: UD fiber, adhesive decals
Nipple material: Aluminum
Spoke type: CX-Sprint
Spoke count: 20
Spoke pattern: 2 Cross, Radial drive, 2 Cross non-drive
Driver body type: n/a, SRAM XDR, SRAM/Shimano Road
Axle type (Wheels) TA 12x100, TA 12x142
Bearings: Cartridge - Steel
Driver Mechanism: 6 Pawls, Compression Springs, n/a
Spoke Length DS: 224mm, 236mm
Spoke Length NDS: 238mm, 240mm
Max outside width: 27mm
Weight Based On Wheel set in lightest configuration: 12mm through axles and XDR body. No tape or valve included. Front: 752g Rear: 883g
Weight (g) 1635
